Function Introduction
01
Body materia
Imported ABS engineering plastic, the whole machine is rolled intoshape, strong acid and alkali corrosion resistance.
02
Battery configuration
Standard 145Ah large capacity maintenance-free battery, endurance5-6hours.
03
Drive system
Adopt rear drive type gear transmission differential motor, speedadjustable, easy and efficient.
04
Water injection port
Large opening design, water injection more convenient and efficient.
05
Overload protection
Equipped with overload protection device,improve the motorservice life.
06
Control system
Simple panellayout, easy to control.
07
Squeegee assembly
Stainless steel and heavy squeegee body, no residue for differentground environment.
Product Application Scenarios
Factory workshop, warehousing logistics, property cleaning, shopping malls, supermarkets.hospitals, schools, airports, stations, stadiums and other places;Epoxy ground, emery ground,terrazzo, cement ground, tile, marble, PVC, wood floor andother grounds.
Parameter List
| Project | Parameter | ||
|---|---|---|---|
| Car model | CHRCHR60SCP/CHR60SCPD | ||
| Product Parameters | Dimension(mm) | 1380*550*1120 | |
| Working efficiency(m/h) | 3200 | ||
| Cleaning width (mm) | 530 | ||
| Solution tank capacity (L) | 60;60 | ||
| Recovertank capacity (L) | 65 | ||
| Brush disc motor (V/W) | 24/600 | ||
| Waterabsorption motor (V/W) | 24/550 | ||
| Drivemotor | Self walking type | ||
| Curb weight(Kg) | 175 | ||
| Endurance time(h) | 3~4 | ||
| Waterabsorption width(mm) | 830 | ||
| Brush disc pressure (Kg) | 30~45 | ||
| Noise level(dB(A) | 68 | ||
| Productivity rate(n/h) | 2800;2800 | ||
| Battery capacity(Ah) | DC24/100 | ||
