Function Introduction
01
Human mechanics design
The ergonomic design of the whole machine makes the operator have a comfortable control feeling
02
Safety and environmental protection
The whole machine adopts maintenance-free performance lead-acid battery as the power source, which is safe and reliable.
03
CAN bus control system
The control system adopts CAN bus control system, with simple lines and precise control.
04
Easy to operate
One-button operation design, simple and safe operation, easy to use and maintain
05
Efficient cleaning
High working efficiency, it can clean at least 2300 square meters per hour, which is equivalent to the cleaning efficiency of five or six cleaning workers
06
Silent motor
55dB(A) ultra-low mute design, suitable for noise-sensitive places.
07
Strong battery life
It can work continuously for 3 hours on a single charge, and the maintenance cost is low.
Product Application Scenarios
Suitable for indoor and railway stations, airports, campuses, communities, large public entertainment venues, subway stations and operations in small areasarea.
Parameter List
| Project | Parameter | ||
|---|---|---|---|
| Car model | CHR55SCP/CHR55SCPD | ||
| Product Parameters | Dimension(mm) | 1245x80×960;1245x800x960 | |
| Maximum total mass(kg) | 180;195 | ||
| Solution tank capacity(u) | 55;55 | ||
| Recover tank capacity | 60;60 | ||
| Drive motor(w) | /;150 | ||
| Cleaning path width(mm) | 500;500 | ||
| Squeegee width(mm) | 785;785 | ||
| Disc brush motor (W) | 550;550 | ||
| Draught fan(W) | 450;450 | ||
| Batteries(m/h) | 2300;2500 | ||
| Operation time(h) | 2.5-3;2-2.5 | ||
| Dc voltage() | 24;24 | ||
| Noise level(dB(A) | ≤55;55 | ||
| Productivity rate(n/h) | 2800;2800 | ||
| Battery capacity(Ah) | 2x12V,100Ah;2x12V,100Ah | ||
