Function introduction
01
Green environmental protection
The whole machine is driven by lithium battery, which is green and environment-friendly.
02
8-hour continuous operation
Power system, long operation time, continuous operation time of more than 8 hours.
03
Flexible
Articulated steering structure, small turning radius and flexible steering control.
04
Broaden your horizons
Panoramic glass cab, wide driving vision.
05
Comfortable driving
Equipped with cold and warm air conditioning, the driving environment is comfortable.
06
high efficiency operation
Efficient cleaning and suction operation system, low operation noise and high cleaning efficiency.
07
Dry and wet dedusting system
The domestic first dry and wet dual-purpose circulating dust removal system meets the operation in the South and North.
08
High level unloading
The unloading mode is designed as high-level self unloading (manual or remote control).
Application scenario
Cleaning, cleaning and decontamination of urban auxiliary roads, secondary trunk roads, some main roads, park scenic spots, scenic belts, squares, high-speed railway airports, industrial parks, schools, communities, back streets and alleys, commercial blocks and other scenes.
parameter list
| project | parameter | |||
|---|---|---|---|---|
| Car model | CHR21SEV | |||
| Product parametersl | Overall dimension | 3500×1190×2050 | ||
| Wheelbase (mm) | 1465 | |||
| Min. ground clearance (mm) | 100 | |||
| Minimum turning radius (mm) | 2600 | |||
| Maximum total mass (kg) | 2300 | |||
| Curb weight (kg) | 1740 | |||
| Water tank volume (L) | 150 | |||
| Dustbin volume (L) | 500 | |||
| Cleaning width (m) | 1.1 ~ 1.8 | |||
| Working speed (km/h) | 1 ~ 10 | |||
| Maximum speed (km / h) | 18 | |||
| Maximum suction density (g / M³) | 2.0 | |||
| Continuous working time (h) | ≥8h | |||
| Max.Gradeability(/) | 20% | |||
| Battery(/) | lithium battery | |||
| Working voltage(v) | 72 | |||
| Battery capacity(Kwh) | 40 | |||
| Charging mode(/) | DC charging pile;Portable charger;Vehicle charging | |||
