Function introduction
01
Safe and stable
The engine and key hydraulic parts are imported from the world's first-line brand products with stable performance and reliable quality.
02
Long operation time
Equipped with 1.9m Large capacity dustbin can be used for single long-time operation to improve operation efficiency.
03
Double circulating water dust suppression system
Equipped with a unique dual circulating water dust reduction system, it can realize the dust reduction of large flow self flowing circulating water and large flow circulating water spraying, and effectively suppress the secondary dust of operation.
04
One machine with multiple functions
It can realize the functions of sweeping, mowing, third brushing, pushing snow, sweeping snow and lifting snow. One machine can be used for multiple functions and realize full-time operation.
Application scenario
Cleaning and cleaning of urban auxiliary roads, secondary trunk roads, some main roads, park scenic spots, scenic spots, industrial parks, airports, high-speed railway squares and other roads.
parameter list
| project | parameter | ||
|---|---|---|---|
| Car model | CHR31Mmin | ||
| Product parametersl | Dimension(L*W*H)(mm) | 4310×1500×2245 | |
| Wheelbase(mm) | 1600 | ||
| Min. ground clearance(mm) | 170 | ||
| Maximum total mass(Kg) | 4050 | ||
| Curb Weight(Kg) | 2700 | ||
| Dustbin volume(L) | 1900 | ||
| Water tank volume(L) | 130 | ||
| Cleaning width(m) | 1.5~2.2 | ||
| Working speed(Km/h) | 1~10 | ||
| Maximum speed(Km/h) | 30 | ||
