Function introduction
01
Safe and stable
The engine and key hydraulic parts are imported from the world's first-line brand products with stable performance and reliable quality.
02
Two way hinged structure
The whole machine adopts two-way hinged structure design, with flexible steering and dexterous operation.
03
Circulating artesian water for dust reduction
Using large flow circulating artesian water to reduce dust can effectively inhibit the secondary dust in the process of action.
04
High level unloading
The box body is made of high-quality stainless steel, which can realize high-level self unloading and reduce the labor intensity of the operator.
Application scenario
Cleaning and cleaning of urban auxiliary roads, secondary trunk roads, some main roads, park scenic spots, scenic spots, industrial parks, airports, high-speed railway squares and other roads.
parameter list
| project | parameter | ||
|---|---|---|---|
| Car model | CHR31Mmini | ||
| Product parametersl | Overall dimension | 3665×1220×2170 | |
| Wheelbase(mm) | 1415 | ||
| Minimum turning radius(mm) | 5700 | ||
| Maximum total mass(Kg) | 2700 | ||
| Curb Weight(Kg) | 1970 | ||
| Water tank volume(L) | 150 | ||
| Cleaning width(mm） | 2150 | ||
| Working speed (Km/h） | 1~10 | ||
| Maximum speed two drive(Km/h） | 30 | ||
| Maximum suction density(mm） | 120 (equivalent diameterat adensityof 2.0 g/cm3) | ||
| Engine power(/) | 30.6kw/2600rpm | ||
