- Function introduction
- Application scenario
- parameter list
Function introduction
01
Safety
Three wheel solid tire design, lighter and more flexible steering; Rear wheel hub brake and integrated mechanical hand brake ensure driving safety.
02
Operation comfort
The water tank is equipped with one-piece rolling plastic and beautiful shell; Equipped with front lighting headlights, suitable for operation when the light is insufficient
03
High efficiency and energy saving
With the patented technology of receiving and throwing, the utilization rate of dustbin can theoretically reach more than 95%.
04
Electric dust removal
Large area bucket filter can effectively filter the dust when the main brush is cleaning; The side brush is easy to replace, which can ensure that the side brush can be replaced in a few minutes.
05
Intelligent main brush
It can be automatically adjusted according to the wear during cleaning; The front baffle of the main brush is lifted vertically, and the height can reach 80mm, which can effectively clean larger leaves and stones
06
Reliability
Equipped with maintenance free high-capacity battery pack 100Ah and intelligent charger; Brand controller, brushless motor and proprietary circuit board ensure the stability and reliability of operation.
Application scenario
Parks, streets, stations, docks, municipal roads, property communities, warehouses, factory workshops, schools, stadiums, large venues, airports and other areas.
parameter list
| project | parameter | |
|---|---|---|
| Car model | chr1800sev | |
| Product parametersl | Dimension(mm) | 2150×1665×1950 |
| Totalmass(kg) | 680 | |
| Rated load(kg) | 150 | |
| cleaning width(m) | ＜1800 | |
| Sweeping speed(km/h) | ≤7 | |
| Walking speed(km/h) | ≤10 | |
| Cleaning power(kw) | 0.8+0.09*4+0.65 | |
| Driving power(kw) | 1.2 | |
| Climbing ability(%) | >25 | |
| Maximum efficiency(m²/h) | 12000 | |
| Main brush length /quantity(mm/) | 650/1 | |
| Side brush diameter/ quantity(mm/) | 500/4 | |
| Turning radius(mm) | 1200 | |
| Power configuration (v/ah) | 48/100 | |
| Water tank volume (L) | 100 | |
| Bin volume (L) | 180 | |
| Filter area(m²) | 6 | |
| Chargerspecification (SMART)(v/a) | 48/15 | |
| Continuous working time(h) | ＜6 | |
