Function introduction
01
Safety
Three wheel large solid tire design, lighter steering and improved trafficability; Rear wheel hub brake and integrated mechanical hand brake ensure driving safety.
02
High operation efficiency
Equipped with front lighting headlights, it is suitable for the mainstream throwing technology during operation when the light is insufficient, which is more efficient, energy-saving and lower failure rate.
03
Intelligent main brush
It can be automatically adjusted according to the wear during cleaning; The front baffle of the main brush is lifted vertically, and the height can reach 80mm, which can effectively clean larger leaves and stones; The standard water tank, high-pressure water pump and stainless steel atomizing fan-shaped nozzle play an effective role in dust control.
04
Electric dust removal
Large area bucket filter can effectively filter the dust when the main brush is cleaning; The side brush is easy to replace, which can ensure that the side brush can be replaced in a few minutes.
05
Reliability
Equipped with maintenance free high-capacity battery pack (Chaowei 52ah) and intelligent charger; Brand controller and brushless motor ensure the stability and reliability of operation.
Application scenario
Parks, streets, stations, docks, municipal roads, property communities, warehouses, factory workshops, schools, stadiums, large venues, airports and other areas.
parameter list
| project | parameter | |
|---|---|---|
| Car model | CHRI25OSEV | |
| Product parametersl | Dimension(mm) | 1450×1000×1300 |
| Totalmass(kg) | 330 | |
| Rated load(kg) | 120 | |
| cleaning width(m) | ≤1250 | |
| Sweeping speed(km/h) | ≤5 | |
| Walking speed(km/h) | ≤10 | |
| Cleaning power(kw) | 0.68+0.09*2+0.35 | |
| Driving power(kw) | 0.8 | |
| Climbing ability(%) | >25 | |
| Maximum efficiency(m²/h) | 5800 | |
| Main brush length /quantity(mm/) | 550 | |
| Side brush diameter/ quantity(mm/) | 500/2 | |
| Turning radius(mm) | 1200 | |
| Power configuration (v/ah) | 48/52 | |
| Water tank volume(L) | 20 | |
| Bin volume(L) | 150 | |
| Filter area(m²) | 4 | |
| Charger specification( SMART)(v/a) | 48/6 | |
| Continuous working time(h) | 2.5 | |
